302A10019X Conec 302A10019X is a 9-position D-Sub receptacle with female sockets and solder cup termination. It features gold-plated contacts, a steel tin-plated shell, and free hanging mounting.
Mfr Part #:

302A10019X

Available from 1 distributors
Mfr Name: Conec
Conec
Conec 302A10019X is a 9-position D-Sub receptacle with female sockets and solder cup termination. It features gold-plated contacts, a steel tin-plated shell, and free hanging mounting.
✓ Total Stock: 50 pcs
$ Price Range: $0.87 - $1.43

302A10019X Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
50 pcs
On Request
50 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

302A10019X Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Style
Connector Type
Contact Finish
Contact Finish Thickness
Contact Type
Current Rating
Current Rating (Amps)
Flange Feature
Ingress Protection
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Rows
Shell Material, Finish
Shell Size, Connector Layout
Tape & Reel
Termination
Termination Style
View Similar Products (0)

302A10019X Description

Short technical summary and product information.

The Conec 302A10019X is a standard D-Sub receptacle connector designed for reliable signal interconnections. It features 9 female socket contacts arranged in 2 rows, with a shell size of DE (E). The connector uses solder cup termination for easy wire attachment and is intended for free hanging (in-line) mounting.



Electrical specifications include a nominal current rating of 7.5A per contact. The contacts are gold-plated with a thickness of 8.00 microinches (0.203 micrometers), ensuring good conductivity and corrosion resistance. The steel shell is tin-plated for durability. The connector is rated IP20 for basic protection against solid objects and has a UL94 V-0 flammability rating for the insulator material.



This connector is suitable for applications requiring a compact, reliable D-Sub interface with solder cup connections. The unthreaded flange feature allows for simple housing or shell mounting.

302A10019X Quick Information

Product Type: D-Sub Connector Assembly
Canonical Name: Conec 302A10019X D-Sub Receptacle, Female Sockets, 9 Position, Solder Cup
Subcategory: Standard D-Sub Connector

302A10019X Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

302A10019X Estimated Pricing

Qty Low High
1+ $1.43 $1.43
10+ $1.25 $1.25
50+ $1.24 $1.24
500+ $1.18 $1.18
1,000+ $1.04 $1.04
2,500+ $0.88 $0.88
5,000+ $0.87 $0.87

Estimated market price range - modelled values for guidance only, not live distributor offers.

302A10019X Features

  • 9-position D-Sub receptacle with female sockets.
  • Solder cup termination for easy wire attachment.
  • Gold-plated contacts rated for 7.5A.
  • Free hanging (in-line) mounting style.
  • Steel shell with tin plating and UL94 V-0 rating.

302A10019X Applications

  • Signal interconnection in industrial control systems.
  • Data communication equipment requiring D-Sub connectors.
  • Test and measurement instrumentation.
  • Free hanging cable assemblies for internal wiring.

302A10019X FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the Conec 302A10019X have?

The connector has 9 positions arranged in 2 rows.

What is the current rating of the 302A10019X?

The nominal current rating is 7.5A per contact.

What mounting type does this connector use?

It is designed for free hanging (in-line) mounting.

What is the contact finish on the 302A10019X?

The contacts have a gold finish with a thickness of 8.00 microinches (0.203 micrometers).

What is the shell material and finish?

The shell is made of steel with a tin plating.

What is the ingress protection rating?

The connector has an IP20 rating.

What is the flammability rating of the insulator?

The material flammability rating is UL94 V-0.
