| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Dimensions | |
| Features | |
| Height | |
| Length | |
| Mounting Feature | |
| Operating Temperature | |
| Power (Watts) | |
| Resistance | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
The Murata Power Solutions 3020-01098-0 is a chassis mount resistor designed for current sensing applications. It features a metal element construction for reliable performance.
Key electrical specifications include a resistance value of 2.5 mOhms with a tight tolerance of ±0.25%. The resistor is rated for 1W of power and has a temperature coefficient of ±15ppm/°C. It operates within a temperature range of -40°C to 60°C.
Mechanically, this component has dimensions of 50.80mm L x 31.70mm W and a height of 42.70mm. It is designed for chassis mounting with flanges. The package type is a rectangular case, supplied in bulk packaging.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 2.5 mOhms.
The tolerance is ±0.25%.
The power rating is 1W.
The operating temperature range is -40°C to 60°C.
It features chassis mounting with flanges.
The dimensions are 50.80mm L x 31.70mm W x 42.70mm H.
