| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
18,304 pcs
|
18304 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The TE Connectivity 3-794618-6 is a shrouded male pin header designed for board-to-cable/wire applications. It features 6 positions arranged in 2 rows with a 3.00mm pitch and 3.00mm row spacing. The connector uses through hole, right angle mounting with solder termination.
The header has a 4-wall shrouded design with a locking ramp fastening system for secure mating. The contacts are made of brass with a tin finish (100.0µin / 2.54µm thickness). The housing is black polyamide (nylon) with a UL94 V-0 flammability rating. The connector is rated for 250V and has an operating temperature range of -40°C to 105°C. A board lock feature is included for additional mechanical retention.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.80 | $1.80 |
| 10+ | $1.63 | $1.63 |
| 25+ | $1.57 | $1.57 |
| 286+ | $1.32 | $1.32 |
| 572+ | $1.23 | $1.23 |
| 1,144+ | $1.18 | $1.18 |
| 5,148+ | $1.12 | $1.12 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions in 2 rows.
3.00mm (0.118") pitch.
250V.
Through hole, right angle mounting.
