| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Board | |
| Cable Pitch | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Row Spacing | |
| Tape & Reel |
The TE Connectivity 3-216791-4 is a 34-position DIP header IDC connector designed for board-in direct wire-to-board applications. It features a 2-row configuration with a row spacing of 0.100" (2.54mm) and a board pitch of 0.100" (2.54mm). The cable pitch is 0.050" (1.27mm), making it suitable for ribbon cable termination via IDC (Insulation Displacement Contact).
The connector is mounted using through hole press-fit technology and has a gray housing. Contacts are finished with tin, with a thickness of 118.1µin (3.00µm). A feed through feature is included, allowing pass-through wiring. The connector is RoHS3 compliant and REACH unaffected, with an MSL of 1 (unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $3.89 | $3.89 |
| 10+ | $3.38 | $3.38 |
| 25+ | $2.77 | $2.77 |
| 120+ | $2.62 | $2.62 |
| 300+ | $2.40 | $2.40 |
| 540+ | $2.23 | $2.23 |
| 1,020+ | $2.17 | $2.17 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 34 positions.
The row spacing is 0.100" (2.54mm).
It uses through hole press-fit mounting.
The contact finish is tin with a thickness of 118.1µin (3.00µm).
It uses IDC (Insulation Displacement Contact) termination.
