| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Industrial Grade | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 3-128-240 is a TA36 Rocker series circuit breaker designed for thermal and thermal-magnetic protection. This 2-pole breaker offers a rated current of 20A and a maximum AC voltage rating of 277 VAC (UL/CSA) or 240 VAC (IEC).
It features a positively trip-free release mechanism and rocker actuation, suitable for panel mounting. The breaker has a conditional short circuit capacity of 2 kA at 240 VAC. Its operating temperature range is -30°C to 60°C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and construction equipment. It is designed for reliable short-circuit protection and overload protection in various industrial and commercial settings.
AC ratings: 240 VAC (IEC) and 277 VAC (UL/CSA). DC ratings: 32 VDC (1-pole) and 60 VDC (2-pole).
-30°C to 60°C.
0.05 to 20 A for AC applications, with magnetic trip up to 16 A.
Panel mount with IP40 front protection.
50,000 switching cycles.
