| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
36,000 pcs
|
36000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Junction Temperature | |
| Power Dissipation | |
| Storage Temperature | |
| Tape & Reel | |
| Transistor Type |
The 2SC4617 from ROHM Semiconductor is a general-purpose NPN bipolar junction transistor (BJT) suitable for small signal amplification applications. It is rated for a collector-emitter voltage (VCEO) of 50V and a continuous collector current (IC) of up to 150mA. The device has a maximum power dissipation (PD) of 150mW.
Key electrical characteristics include a typical DC current gain (hFE) ranging from 120 to 390 at 6V and 1mA, and a transition frequency (fT) of 180MHz at 12V and -2mA. The output capacitance (Cob) is typically 2.0pF at 12V and 1MHz.
The 2SC4617 is available in a SOT-416 (EMT3) package, also referenced as SOT-523 by some manufacturers. This small surface-mount package is suitable for automated assembly processes.
This transistor complements the 2SA1774 FRA and is AEC-Q101 qualified, indicating its suitability for automotive applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum collector-emitter voltage (VCEO) for the 2SC4617 is 50V.
The continuous collector current (IC) for the 2SC4617 is 150mA.
The maximum power dissipation (PD) for the 2SC4617 is 150mW.
The typical DC current gain (hFE) for the 2SC4617 is between 120 and 390 under specific test conditions (VCE=6V, IC=1mA).
The 2SC4617 is available in a SOT-416 package, also known as EMT3 or SOT-523.
Yes, the 2SC4617 is AEC-Q101 qualified.
