The 2N1701 is a general-purpose NPN bipolar junction transistor (BJT) manufactured by Multicomp Pro. It is designed for various electronic applications requiring amplification or switching.
Key electrical characteristics include a maximum collector current of 2.5A and a maximum collector-emitter voltage of 40V. The transistor exhibits a minimum DC current gain (hFE) of 20 and a nominal transition frequency of 0.35MHz. It is constructed with a silicon element.
The 2N1701 is housed in a TO-8 cylindrical package with a through-hole mounting type. The terminals are wire-formed and positioned at the bottom, with a tin-lead finish. The package body material is metal. This transistor is suitable for general-purpose power applications.
This component is part of the discrete semiconductor product family, specifically categorized under single NPN transistors. Its robust specifications make it a reliable choice for numerous electronic circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.09 | $0.09 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum collector current is 2.5 A.
The maximum collector-emitter voltage is 40 V.
The minimum DC current gain is 20.
The transition frequency is 0.35 MHz.
It is an NPN silicon transistor.
The 2N1701 is supplied in a TO-8 cylindrical metal package with three wire terminals.
It has one element and three terminals.
