Mfr Part #:

2EDN7523F

Mfr Name: Infineon

The Infineon 2EDN7523F is a dual-channel, low-side gate driver designed for high-speed switching applications. It features a 5A peak output current and operates with a supply voltage range of 4.5V to 20V.

✓ Total Stock: 1,696 pcs

$ Price Range: $2.01

2EDN7523F Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Xingangxin ✓ Non-Authorised Inventory information	1,696 pcs On Request	1696 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

2EDN7523F Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Infineon
Lead Style	Gull Wing
Mounting Type	Surface Mount
Propagation Delay	17 ns
SVHC Present	Not Present
Slew Rate	5 ns
Voltage	4.5 V to 20 V

View Similar Products (0)

2EDN7523F Description

Short technical summary and product information.

The Infineon 2EDN7523F is a high-speed, dual-channel, low-side gate driver from the EiceDRIVER™ family. It is designed to efficiently drive power MOSFETs and GaN switches in applications such as switch-mode power supplies (SMPS).

Key electrical characteristics include a 5A peak output current capability per channel, a fast propagation delay of 17 ns, and a rapid slew rate of 5 ns. The device operates with a supply voltage ranging from 4.5V to 20V.

This gate driver is housed in a PG-DSO-8-60 package, suitable for surface-mount applications. Its design focuses on enabling highly efficient SMPS by providing precise control over fast switching components.

Environmental compliance includes RoHS3 compliance, MSL Level 1, and REACH unaffected status, though these are currently unverified.

2EDN7523F Quick Information

Product Type: Gate Driver

Series: 2EDN752x / 2EDN852x

Canonical Name: Infineon 2EDN7523F Dual Channel Low-Side Gate Driver

Subcategory: Low-Side Gate Driver

2EDN7523F Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

2EDN7523F Estimated Pricing

Qty	Low	High
1+	$2.01	$2.01

Estimated market price range - modelled values for guidance only, not live distributor offers.

2EDN7523F Features

Dual-channel low-side gate driver
5A peak output current capability
17 ns propagation delay
4.5V to 20V supply voltage range
PG-DSO-8-60 surface mount package

2EDN7523F Applications

Used in switch-mode power supplies.
Ideal for motor drive circuits.
Suitable for DC-DC converter designs.
Applicable in half-bridge topologies.

2EDN7523F FAQs

5 frequently asked questions generated from this part’s specifications.

What is the supply voltage range of the 2EDN7523F?

The supply voltage range is 4.5V to 20V.

What package is the 2EDN7523F available in?

The device is available in a PG-DSO-8-60 surface-mount package.

What is the peak output current per channel?

The peak output current is 5A per channel.

What is the propagation delay of the 2EDN7523F?

The propagation delay is 17ns.

What is the slew rate of the 2EDN7523F?

The slew rate is 5ns.
