| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Ambient Temperature | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
The Altech Corporation 2CU25L is a miniature circuit breaker designed for reliable circuit protection. This thermal magnetic breaker is rated for 25A and features a 2-pole configuration, suitable for 480V AC applications.
Designed for ease of installation, the 2CU25L utilizes a DIN rail mounting type, making it compatible with standard industrial mounting systems. Its robust construction includes strong terminal barriers and a lever actuator for clear ON/OFF indication. The breaker has an interrupting capacity of 10kA and is recognized by UL489, cULus, and CE.
Environmental and operational specifications include an operating temperature range of -25°C to 60°C and a storage temperature range of -25°C to 75°C. The terminal protection is rated at IP20. With a mechanical life of 10,000 switching cycles and an electrical life of 6,000 switching cycles, the 2CU25L is built for durability and long-term performance in various industrial and commercial applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 25A.
The voltage rating is 480V.
It has 2 poles.
It is a Thermal Magnetic breaker.
It is mounted on a DIN Rail.
The approval agencies are CE, cULus, and UL489.
The interrupting capacity is 10kA.
