The Altech Corporation 2C25DL is a two-pole mini circuit breaker rated for 25A and 250V DC. It utilizes a thermal magnetic tripping mechanism and is designed for DIN rail mounting, making it suitable for various industrial control panel applications.
This circuit breaker offers a degree of protection of IP20 and has an electrical life of 6,000 switching cycles and a mechanical life of 10,000 switching cycles. It operates within an ambient temperature range of -25°C to +70°C and is manufactured in Germany.
Key specifications include a rated current of 25A and a rated voltage of 250V DC. The breaker is built to withstand mechanical shocks up to 25g at 11ms and vibration resistance of over 15G. Terminal size acceptability is for wires from 18-3 AWG on top and 18-2 AWG on the bottom, with a recommended terminal torque between 2 and 2.5 Nm.
Compliance includes cULus and IEC approvals. The standard pack quantity is 6 units. This component is part of the DLS9 Series C-Trip (DC) line.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The rated current is 25A.
The rated voltage is 250V DC.
It has two poles.
The ambient temperature range is -25°C to +70°C.
The degree of protection is IP20.
The electrical life is 6,000 switching cycles ON/OFF.
The mechanical life is 10,000 switching cycles ON/OFF.
