| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
102 pcs
|
102 pcs | On Request | 1 | On Request | On Request | 16+ | On Request | On Request | |
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Max) | |
| DC Resistance (DCR) (Max) | |
| Filter Type | |
| Height (Max) | |
| Impedance @ Frequency | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Lines | |
| Operating Temperature | |
| Tape & Reel | |
| Termination Style | |
| Width |
The 29F0318-1SR-10 is a three-line ferrite bead designed for power line noise suppression. It provides 119 Ω impedance at 100 MHz, with a maximum DC resistance of 10 mΩ and a current rating of 6 A. This component is housed in a 6-SMD package with flat leads for surface mount assembly.
Measuring 4.83 mm in length, 4.50 mm in width, and 4.19 mm in height, the device operates over a temperature range of -40°C to 125°C. The three-line configuration allows effective common-mode noise filtering in DC power lines.
Typical applications include EMI suppression in automotive electronics, portable devices, and other power distribution systems. The surface mount design facilitates automated assembly and high-density board layouts.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.82 | $2.82 |
| 10+ | $2.36 | $2.36 |
| 25+ | $2.15 | $2.15 |
| 100+ | $1.69 | $1.69 |
| 250+ | $1.64 | $1.64 |
| 500+ | $1.54 | $1.54 |
| 900+ | $1.48 | $1.48 |
| 1,800+ | $1.45 | $1.45 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
119 Ω at 100 MHz.
6 A.
10 mΩ maximum.
-40°C to 125°C.
6-SMD with flat leads.
Listed as RoHS3 compliant.
Surface mount.
