| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
980 pcs
|
980 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The TE Connectivity 292207-7 is a 7-position, single-row male pin header with a 1.50mm pitch. It is designed for board-to-cable/wire applications and features a shrouded 4-wall design with detent lock fastening for secure mating. The header is through-hole mounted and terminated with kinked pins for solder connection.
The contacts are made of brass with a tin finish, providing reliable conductivity. The insulation is molded from gray polyamide (nylon) glass-filled material, rated UL94 V-0 for flammability. The header operates over a temperature range of -30°C to 105°C and is voltage rated at 50VAC. A board guide feature aids in alignment during assembly.
This connector is suitable for compact electronic assemblies where space is constrained. The 1.50mm pitch allows for high-density wiring, while the shroud provides protection to the pins. The detent lock ensures a firm connection, reducing the risk of accidental disconnection.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.71 | $0.71 |
| 10+ | $0.61 | $0.61 |
| 100+ | $0.52 | $0.52 |
| 250+ | $0.46 | $0.46 |
| 1,150+ | $0.43 | $0.43 |
| 2,300+ | $0.42 | $0.42 |
| 5,750+ | $0.37 | $0.37 |
| 10,350+ | $0.37 | $0.37 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
7 positions.
1.50mm (0.059 inches).
50VAC.
Through Hole.
Varies by wire gauge.
-30°C to 105°C.
Tin.
