| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
500 pcs
|
500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Backwall/Post Interruptions | |
| Centerline | |
| Connector System | |
| Connector Type | |
| Contact Base Material | |
| Contact Current Rating (A) | |
| Contact Design | |
| Contact Finish | |
| Contact Layout | |
| Contact Length | |
| Contact Material | |
| Contact Mating Area Plating Material | |
| Contact Mating Area Plating Thickness | |
| Contact Retention | |
| Contact Retention Type | |
| Contact Shape | |
| Contact Termination Area Plating Material | |
| Contact Termination Area Plating Thickness | |
| Contact Transmits (Typical) | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Header Type | |
| Height | |
| Housing Color | |
| Housing Material | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Length | |
| Material Flammability Rating | |
| Mating Alignment | |
| Mating Alignment Type | |
| Mating Post Length | |
| Mating Retention | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature Range | |
| Operating Voltage | |
| PCB Mount Alignment | |
| PCB Mount Retention | |
| PCB Mount Retention Type | |
| PCB Mounting Orientation | |
| PCB Mounting Style | |
| PCB Thickness Recommended | |
| Panel Mount Retention | |
| Pitch | |
| Sealed | |
| Shrouding | |
| Strain Relief | |
| Style | |
| Tail Orientation | |
| Tape & Reel | |
| Termination | |
| Termination Method to PC Board | |
| Voltage Rating | |
| Width | |
| Wire/Cable Size (AWG) |
The TE Connectivity 292173-4 is a 4-position, single row, shrouded header from the AMP CT series. It features a 2.00mm pitch and a surface mount, right angle mounting orientation, making it suitable for compact wire-to-board applications. The header is fully shrouded with a 4-wall design and includes a detent lock for secure mating.
The contacts are made of brass with a tin plating on both the mating and termination areas, with a plating thickness of 1 to 2 micrometers. The insulation is black polyamide (PA6T) glass filled material with a UL94 V-0 flammability rating. The header includes board guide and solder retention features for reliable PCB mounting.
Electrical ratings include a contact current rating of 4A and an operating voltage of 125 VAC/VDC. The operating temperature range is -40°C to 221°C. The connector system is wire-to-board and accepts 28 to 22 AWG discrete wire.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.66 | $1.66 |
| 10+ | $1.41 | $1.41 |
| 100+ | $1.20 | $1.20 |
| 500+ | $1.00 | $1.00 |
| 1,000+ | $0.94 | $0.94 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.00mm (0.079 inches).
It has 4 positions in a single row.
The contact current rating is 4A.
The operating voltage is 125 VAC / 125 VDC.
It uses surface mount, right angle mounting.
The operating temperature range is -40°C to 221°C.
It accepts 28 to 22 AWG wire.
