| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Features | |
| Height | |
| Length | |
| Mounting Style | |
| Mounting Type | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Switching Voltage | |
| Termination Style | |
| Width |
The Phoenix Contact 2905660 is a general-purpose industrial relay with a Single Pole Double Throw (SPDT) contact form, also known as 1 Form C. It is designed to handle a contact current rating of 8 Amps and operates with a 24VDC coil voltage. The relay features a non-latching coil type and includes a diode, lighted indicator, and socket.
This relay is suitable for various applications requiring reliable switching. It has an operate time of 9 ms and a release time of 10 ms. The switching voltage is rated for a maximum of 250VAC and 250VDC. The contact material is Silver Nickel (AgNi), known for its durability and conductivity.
For mounting, the 2905660 utilizes a DIN rail mounting style, making it easy to integrate into standard industrial control panels. The termination style is screw terminal, ensuring secure connections. The operating temperature range for this relay is from -40°C to 60°C, allowing for use in diverse environmental conditions. The IP rating is IP20.
Additional specifications include a coil current of 18 mA and features such as a diode and lighted indicator. The product dimensions are 75 mm in length, 16 mm in width, and 89 mm in height.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage is 24VDC.
The contact current rating is 8A.
It has an SPDT (1 Form C) contact form.
The operating temperature range is -40°C to 60°C.
It is mounted on a DIN rail.
The switching voltage is a maximum of 250VAC and 250VDC.
The dimensions are 75 mm in length, 16 mm in width, and 89 mm in height.
