2903361 The Phoenix Contact 2903361 is a general purpose relay module with a 24VDC coil and a 6A contact rating. It features a SPST-NO contact form and push-in connection.
Mfr Part #:

2903361

Available from 1 distributors
Mfr Name: Phoenix Contact
Phoenix Contact
The Phoenix Contact 2903361 is a general purpose relay module with a 24VDC coil and a 6A contact rating. It features a SPST-NO contact form and push-in connection.
✓ Total Stock: 60 pcs
$ Price Range: $2.00

2903361 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ADI/AAR OEM Supply ✓
Non-Authorised Inventory information
60 pcs
On Request
60 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

2903361 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Coil Current
Coil Type
Coil Voltage
Contact Form
Contact Material
Contact Rating (Current)
Depth
Features
Height
Mounting Type
Operate Time
Operating Mode
Operating Temperature
Relay Type
Release Time
Switching Voltage
Termination Style
Width
View Similar Products (0)

2903361 Description

Short technical summary and product information.

This Phoenix Contact relay module, part number 2903361, is designed for general-purpose applications. It operates with a nominal input voltage of 24V DC and has a coil current of 9 mA.



The relay features a single normally open (SPST-NO) contact configuration with a contact material of Silver Tin Oxide (AgSnO). It can handle a maximum switching voltage of 250V AC/DC and a limiting continuous current of 6A. The module includes a diode for protection and a lighted indicator.



Designed for easy installation, this relay module utilizes a push-in connection method and is suitable for DIN rail mounting. It operates within an ambient temperature range of -40°C to 60°C and has a mechanical service life of approximately 2 x 10^7 cycles.

2903361 Quick Information

Product Type: Relay Module
Series: RIF-0-RPT
Canonical Name: Phoenix Contact RIF-0-RPT-24DC/1 Relay Module
Subcategory: General Purpose Relay

2903361 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

2903361 Estimated Pricing

Qty Low High
1+ $2.00 $2.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

2903361 Features

  • General purpose relay module with 24VDC coil.
  • Features a 6A continuous current rating.
  • SPST-NO contact configuration for switching.
  • Utilizes convenient push-in connection method.
  • Designed for DIN rail mounting applications.

2903361 Applications

  • Ideal for industrial control circuits.
  • Suitable for automation systems.
  • Used in power distribution panels.
  • Applicable in building automation.

2903361 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the coil voltage for the Phoenix Contact 2903361 relay?

The nominal input voltage for the Phoenix Contact 2903361 relay is 24 V DC.

What is the maximum continuous current rating for this relay?

The limiting continuous current for this relay is 6 A.

What type of contact form does the 2903361 relay have?

The 2903361 relay has a 1 N/O contact form, also known as SPST-NO.

What is the operating temperature range for this relay module?

The relay module can operate in temperatures ranging from -40 °C to 60 °C.

How is the Phoenix Contact 2903361 relay mounted?

This relay module is designed for DIN rail mounting.
