| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7 pcs
|
7 pcs | On Request | 1 | On Request | On Request | 1206 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Voltage | |
| SVHC Present | |
| Type |
The Connor-Winfield TB/TVB series comprises 5x7mm Temperature Compensated Crystal Oscillators (TCXO) and Voltage Controlled Crystal Oscillators (VCTCXO) designed for high performance and stability. These components feature exceptional frequency stability, with options ranging from +/-0.28 ppm to +/-2.00 ppm, and low phase noise.
Available in 4-pad (TVB series) or 10-pad (TB series) surface mount footprints, these devices operate at a 3.3 Vdc supply voltage. They offer output logic options of LVCMOS or Clipped Sinewave and boast low jitter performance of less than 0.50 ps RMS. The TB model series also includes a Tri-State Enable/Disable feature.
These TCXO/VCTCXO units are suitable for demanding applications such as IEEE 1588 PTP and Synchronous Ethernet, as well as wireless communications, small cells, test and measurement, and GPS applications. They are supplied in tape and reel packaging and are RoHS compliant.
Key specifications include frequency stabilities of +/-0.28 ppm (10-50 MHz) and +/-0.50 ppm, +/-1.00 ppm, or +/-2.00 ppm (10-100 MHz). Available temperature ranges are 0 to 85°C, 0 to 70°C, -40 to 85°C, and -20 to 70°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Frequency stabilities available are +/-0.28 ppm (10 to 50 MHz), and +/-0.50 ppm, +/-1.00 ppm, or +/-2.00 ppm (10 to 100 MHz).
Available temperature ranges include 0 to 85°C, 0 to 70°C, -40 to 85°C, and -20 to 70°C.
The package size is 5x7mm, available in 4-pad (TVB series) or 10-pad (TB series) surface mount footprints.
The operating voltage is 3.3 Vdc.
Output logic options include LVCMOS or Clipped Sinewave.
The jitter is less than 0.50 ps RMS.
Yes, it is RoHS3 Compliant and Lead Free.
