| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Current | |
| Features | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Pitch | |
| Positions Per Level | |
| Tape & Reel | |
| Termination Style | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The TE Connectivity 284391-4 is a 4-position wire to board terminal block with a 3.50mm pitch. It features side wire entry for horizontal mating with the PCB and uses a screw-rising cage clamp termination for secure wire connections. The terminal block is rated for 12A and 300V, supporting wire gauges from 14 to 30 AWG. It is green in color and includes side interlocking features for multi-position assembly. The through hole mounting allows for reliable soldering, and the component is wave solder process capable at 265°C for 10 seconds. Dimension A is 14.0mm. Per the datasheet, all part numbers are RoHS compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.57 | $2.57 |
| 10+ | $1.84 | $1.84 |
| 25+ | $1.61 | $1.61 |
| 50+ | $1.48 | $1.48 |
| 100+ | $1.36 | $1.36 |
| 300+ | $1.25 | $1.25 |
| 600+ | $1.18 | $1.18 |
| 1,050+ | $1.15 | $1.15 |
| 5,100+ | $1.11 | $1.11 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions.
3.50mm (0.138").
12A.
300V.
Through hole.
14-30 AWG.
Screw - Rising Cage Clamp.
