| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Current | |
| Features | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The TE Connectivity 282843-2 is a 2 position wire to board terminal block designed for reliable PCB connections. It features a 10.16mm pitch and supports wire gauges from 12 to 30 AWG. The terminal block is rated for 17.5A current and 600V voltage, making it suitable for power distribution applications.
The component uses a screw rising cage clamp termination for secure wire retention and is mounted through hole on the PCB. The mating orientation is horizontal with the board, allowing side entry of wires. The body is green and includes side interlocking features for multi-position assembly.
This terminal block is RoHS3 compliant and has an MSL of 1 (unlimited). It is commonly used in industrial control, power supplies, and building automation systems where robust wire connections are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.38 | $1.38 |
| 10+ | $1.00 | $1.00 |
| 25+ | $0.87 | $0.87 |
| 50+ | $0.79 | $0.79 |
| 100+ | $0.65 | $0.65 |
| 200+ | $0.65 | $0.65 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
2 positions.
10.16mm (0.400 inches).
17.5 A.
600 V.
Through hole.
12-30 AWG.
Screw rising cage clamp.
