| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,800 pcs
|
3800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The TE Connectivity 281742-4 is a 2-row, 8-position (all loaded) shrouded header designed for board-to-cable/wire applications. It features a 2.54mm pitch and 2.54mm row spacing. The connector uses square male pin contacts made of phosphor bronze with a tin finish. The insulation is blue thermoplastic with a flammability rating of UL94 V-0. Mounting is through-hole, right angle, with solder termination. The header includes a friction lock fastening type for secure mating. The insulation height is 7.62mm and the contact length is 7.00mm. Operating temperature range is -40°C to 100°C. This component is suitable for various interconnect applications requiring a reliable, keyed connection.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.94 | $1.94 |
| 10+ | $1.65 | $1.65 |
| 25+ | $1.63 | $1.63 |
| 100+ | $1.41 | $1.41 |
| 250+ | $1.39 | $1.39 |
| 500+ | $1.25 | $1.25 |
| 1,000+ | $1.14 | $1.14 |
| 2,500+ | $1.02 | $1.02 |
| 5,000+ | $0.98 | $0.98 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 8 positions in 2 rows, all loaded.
It is a through-hole, right angle mount with solder termination.
The operating temperature range is -40°C to 100°C.
It uses a friction lock.
The contacts are made of phosphor bronze with a tin finish.
The insulation is blue thermoplastic with a UL94 V-0 flammability rating.
