| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,839 pcs
|
3839 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
51 pcs
|
51 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
18 pcs
|
18 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| China RoHS | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| ELV | |
| Fastening Type | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Solder Process Capability | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The 281739-5 is a 10-position (2x5) shrouded header from TE Connectivity, part of the HE14 series. It features a 2.54mm pitch and 2.54mm row spacing, with through-hole mounting and solder termination. The header is shrouded with 2 walls and includes a friction lock for secure mating. Contacts are made of phosphor bronze with tin plating, and the insulation is blue thermoplastic rated UL94 V-0. Operating temperature range is -40°C to 100°C, and it is wave solder capable to 265°C. This connector is suitable for board-to-cable/wire applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.30 | $2.30 |
| 10+ | $2.25 | $2.25 |
| 100+ | $1.91 | $1.91 |
| 500+ | $1.71 | $1.71 |
| 1,000+ | $1.61 | $1.61 |
| 2,000+ | $1.43 | $1.43 |
| 4,000+ | $1.38 | $1.38 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10 positions in 2 rows (2x5).
2.54mm (0.100")
Through hole with solder termination.
-40°C to 100°C.
Blue thermoplastic, UL94 V-0 rated.
Yes, it is a 2-wall shrouded header with friction lock.
Phosphor bronze with tin plating.
