| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,061 pcs
|
4061 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The TE Connectivity 281739-3 is a 6-position, 2-row, 2.54mm pitch header designed for board-to-cable/wire applications. It features a shrouded 2-wall design with a friction lock for secure mating. The male pins are made of phosphor bronze with a tin finish, and the insulation is thermoplastic with a UL94 V-0 flammability rating in blue color.
This header is through-hole mounted and terminated by solder. The contact length is 7.00mm with an overall contact length of 12.50mm, and the insulation height is 11.40mm. Operating temperature range is -40°C to 100°C. The connector is RoHS3 compliant, REACH unaffected, and has an MSL of Level 1.
Typical applications include wire-to-board connections in industrial, automotive, and consumer electronics where a reliable friction lock interface is required. The 2.54mm pitch is standard for many interconnect systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.41 | $1.41 |
| 10+ | $1.20 | $1.20 |
| 250+ | $1.03 | $1.03 |
| 500+ | $0.93 | $0.93 |
| 1,000+ | $0.85 | $0.85 |
| 2,000+ | $0.69 | $0.69 |
| 4,000+ | $0.67 | $0.67 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions.
2.54mm (0.100 inches).
Through-hole.
-40°C to 100°C.
Yes, it has a shrouded 2-wall design with friction lock.
Phosphor bronze with tin finish.
Thermoplastic with UL94 V-0 flammability rating.
