The Wago 281-612 is a 2-conductor fuse terminal block from the 281 Series, designed for DIN rail mounting (35 x 15 and 35 x 7.5 mm). It utilizes CAGE CLAMP push-in spring clamp technology for fast and reliable wire connections. The terminal block accepts conductor cross-sections from 0.08 to 4 mm² and requires a strip length of 9 to 10 mm.
Rated at 800V nominal voltage and 10A rated current per IEC/EN 60947-7-3, this fuse terminal block features a pivoting fuse holder for cylindrical fuses (5 x 25 mm). It is suitable for overload and short-circuit protection applications. The maximum power loss varies by arrangement: 2.5 W (individual) and 1.6 W (block) for overload and short-circuit protection, and 4 W for short-circuit protection only.
The block is rated for overvoltage category III and pollution degree 3, with an impulse withstand voltage of 8 kV. It supports front-entry wiring and is compatible with copper and aluminum conductors. The gray housing is designed for industrial control panels and distribution systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $21.80 | $21.80 |
| 10+ | $15.59 | $15.59 |
| 25+ | $13.93 | $13.93 |
| 50+ | $12.94 | $12.94 |
| 100+ | $12.14 | $12.14 |
| 250+ | $11.34 | $11.34 |
| 500+ | $10.89 | $10.89 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal voltage rating is 800 V per IEC/EN 60947-7-3.
The rated current is 10 A per IEC/EN 60947-7-3.
It uses CAGE CLAMP push-in spring clamp technology.
It supports conductor cross-sections from 0.08 to 4 mm².
It accepts cylindrical fuses of 5 x 25 mm size.
It mounts on DIN rail 35 x 15 and 35 x 7.5 mm.
The rated impulse withstand voltage is 8 kV per IEC/EN 60947-7-3.
