| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
18 pcs
|
18 pcs | On Request | 1 | On Request | On Request | 99 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Built-in Resistor | |
| Color | |
| Conductor Cross Section (Minimum/Maximum @ solid) | |
| Conductor Cross Section (Minimum/Maximum @ stranded) | |
| Features | |
| Flammability Rating | |
| Height (NS 35/7.5) | |
| Insulating Material | |
| Insulating Material Group | |
| Length | |
| Mounting Type | |
| Nominal Voltage | |
| Number of Levels | |
| Number of Positions | |
| Pollution Degree | |
| Rated Surge Voltage | |
| SVHC Present | |
| Standard | |
| Standard Package Quantity | |
| Surge Voltage Category | |
| Terminal | |
| Termination Style | |
| Type | |
| Voltage | |
| Width | |
| Wire Gauge (AWG) | |
| Wire Gauge or Range |
The Phoenix Contact 2775249 (UDK 4-DUR 249) is a feed through modular terminal block designed for DIN rail mounting. It features a screw connection termination style and accepts solid conductors from 0.2 mm² to 6 mm² and stranded conductors from 0.2 mm² to 4 mm² (24-10 AWG).
The terminal block has 4 connections arranged in 2 levels and is rated for a nominal voltage of 630V with a rated surge voltage of 6 kV (pollution degree 3, surge voltage category III, insulating material group I). It is built with a gray polyamide (PA) insulating material rated UL94 V2.
This component includes a built-in 249 Ohm resistor. It is RoHS compliant since August 1, 2006 and conforms to IEC 60947-7-1. The dimensions are 63.5 mm length, 6.2 mm width, and 47 mm height when mounted on NS 35/7.5 rail. Standard package quantity is 50 pieces.
| Qty | Low | High |
|---|---|---|
| 1+ | $17.89 | $17.89 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal voltage is 630V.
It has 4 positions (connections) arranged in 2 levels.
It accepts solid wire from 0.2 mm² to 6 mm² and stranded wire from 0.2 mm² to 4 mm², equivalent to 24 to 10 AWG.
It is designed for DIN rail mounting (NS 35/7.5, NS 35/15, NS 32).
Yes, it has a built-in 249 Ohm resistor.
