| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Depth | |
| For Use With | |
| Height | |
| Number of Poles | |
| Rated Current | |
| Rated Voltage | |
| Weight | |
| Width |
The Wago 272-304 is an insulated PUSH WIRE connector from the Series 272, designed for reliable power supply connections. This connector utilizes PUSH WIRE® technology for efficient and secure wire termination.
Key electrical specifications include a rated current of 18 A and a rated voltage of 400 V, with a rated impulse voltage of 4 kV. It supports solid conductors ranging from 0.5 to 1.5 mm² (20-16 AWG) and also 0.5 to 2.5 mm² (20-14 AWG) with a strip length of 8 to 9 mm. The connector has 4 poles and a total of 16 connection points across 4 potentials.
Mechanically, the Wago 272-304 has a depth of 24.5 mm, a height of 19 mm, and a width of 38.5 mm, with a weight of 12.678 g. It is supplied in a bag packaging type. The overvoltage category is III with a pollution degree of 2.
This connector is suitable for applications requiring secure and easy wire connections in power supply units and other electrical systems where reliable performance is essential.
4 poles.
18 A.
400 V.
Solid conductors from 0.5 to 1.5 mm² (20-16 AWG) and from 0.5 to 2.5 mm² (20-14 AWG).
8 to 9 mm (0.31 to 0.35 inches).
Overvoltage category III.
Width 38.5 mm, height 19 mm, depth 24.5 mm.
