| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
25 pcs
|
25 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Plating | |
| Current | |
| Depth | |
| Features | |
| Height | |
| Lead Spacing | |
| Lead Style | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Voltage | |
| Width | |
| Wire Gauge | |
| Wire Termination |
The Wago 2716-257 is a 7-pole PCB terminal block from the 2716 series. It has a 15 mm pitch and is designed for through-hole mounting. It uses CAGE CLAMP® spring cage termination for quick and tool-free connection of conductors from 1.5 to 16 mm² (6-16 AWG).
Electrical ratings include UL 65 A and 600 V, IEC 76 A and 800 V, with an impulse withstand voltage of 8 kV. The lever actuation allows easy opening and closing of the clamp.
Mechanical dimensions are 100 mm width, 33.3 mm height, and 35 mm depth. The color is gray and contacts are tin-plated. It has a single jumper slot for commoning. Wire strip length is 12-13 mm and the mating orientation is horizontal with board, conductor insertion angle 30°.
Applications include power distribution in industrial control panels, PCB interconnect, and rail-mount terminal block feedthrough. The lever makes it easy to use in confined spaces.
| Qty | Low | High |
|---|---|---|
| 1+ | $31.23 | $31.23 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 7 poles.
The pin spacing is 15 mm.
UL ratings are 65 A and 600 V.
IEC ratings are 76 A, 800 V, with an impulse withstand voltage of 8 kV.
It accepts 6-16 AWG (1.5-16 mm²) solid or fine-stranded conductors.
It uses CAGE CLAMP® screwless spring cage termination with lever actuation.
It is a through-hole (THT) mount terminal block.
