| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
37 pcs
|
37 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuation Type | |
| Color | |
| Conductor Connection Direction to PCB | |
| Conductor Cross Section | |
| Connection Technology | |
| Current | |
| Current Rating | |
| Depth | |
| Features | |
| Height | |
| Lead Spacing | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Pitch | |
| Positions Per Level | |
| Rated Current | |
| Rated Impulse Withstand Voltage | |
| Rated Voltage (@ Overvoltage Category III, Pollution Degree 3) | |
| Rated Voltage (Unspecified condition) | |
| Solder Pin Dimensions | |
| Solder Process | |
| Strip Length | |
| Termination Style | |
| Voltage | |
| Voltage Rating | |
| Width | |
| Wire Gauge | |
| Wire Termination |
The Wago 2716-155 is a 5-position, single-level PCB terminal block from the 2716 series, designed for wire-to-board applications requiring reliable high-current connections. It has a 10.00mm pin spacing and accommodates solid or fine-stranded conductors from 1.5 to 16 mm² (6-16 AWG). The lever-actuated CAGE CLAMP® connection system provides a maintenance-free spring cage termination, eliminating the need for ferrule crimping.
Electrical ratings include a UL rated current of 55A at 300V and an IEC rated current of 76A at 320V. The rated impulse withstand voltage is 4 kV per IEC/EN 60664-1. Conductor connection is at a 30° angle to the PCB. Required strip length is 12 to 13 mm.
This gray terminal block is through-hole (THT) solderable, with solder pin dimensions of 0.95 x 1.2 mm. Its compact mechanical dimensions are 50 mm (width) x 33.3 mm (height) x 35 mm (depth). The part is suitable for use as a pluggable PCB connector, panel feedthrough header, or rail-mount terminal block connector.
| Qty | Low | High |
|---|---|---|
| 1+ | $22.22 | $22.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
