| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Cord Length | |
| Current | |
| Duration | |
| Efficiency | |
| Form | |
| Height | |
| Industrial Grade | |
| Input Connector | |
| Input Type | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage | |
| Width |
This is a wall mount AC/DC adapter from Ideal Power Ltd., part number 25HK-AB-060A300-D56. It provides a regulated 6V DC output at up to 3A, with a maximum power of 18W. The adapter accepts a universal input voltage range of 90 to 264 VAC.
The adapter features Level VI efficiency and is designed for ITE (commercial) applications. It is certified to safety standard 62368-1 and carries approvals from CB, CE, cUL, FCC, GS, RCM, TUV, and UL. The operating temperature range is 0°C to 40°C.
The mechanical form is a wall mount (Class I) with an IEC 320-C8 input connector and includes multi-blade plugs. The output is via a barrel plug with 2.1mm inner diameter and 5.5mm outer diameter, with a cord length of 1.20m. The adapter dimensions are 99.0mm x 52.0mm x 36.0mm. Packaging is in a box.
90 to 264 VAC.
0°C to 40°C.
6V at 3A (18W).
Barrel plug, 2.1mm I.D. x 5.5mm O.D. x 12.0mm.
IEC 62368-1, with approvals from CB, CE, cUL, FCC, GS, RCM, TUV, and UL.
Level VI.
IEC 320-C8, with included multi-blade plugs.
