2512063017Y0 Single-line surface mount ferrite bead with 300 Ohm impedance at 100 MHz. Rated for 350mA with 200mOhm DCR.
Mfr Part #:

2512063017Y0

Available from 2 distributors
Mfr Name: Fair-Rite Products Corp.
Fair-Rite Products Corp.
Single-line surface mount ferrite bead with 300 Ohm impedance at 100 MHz. Rated for 350mA with 200mOhm DCR.
✓ Total Stock: 5,940 pcs
$ Price Range: $0.18 - $0.35

2512063017Y0 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
3,000 pcs
On Request
3000 pcs On Request 1 On Request On Request On Request On Request On Request
Bristol Electronics ✓
Non-Authorised Inventory information
2,940 pcs
On Request
2940 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

2512063017Y0 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current Rating (Max)
DC Resistance (DCR) (Max)
Filter Type
Height (Max)
Impedance @ Frequency
Length
Mounting Type
Number of Lines
Operating Temperature
Storage Temperature
Tape & Reel
Width
View Similar Products (0)

2512063017Y0 Description

Short technical summary and product information.

The Fair-Rite 2512063017Y0 is a surface mount ferrite bead designed for signal line filtering applications. It provides a nominal impedance of 300 Ohms at 100 MHz, effectively suppressing high-frequency noise in electronic circuits.



This component is rated for a maximum DC current of 350mA and features a low DC resistance of 200mOhm, minimizing power loss and heat generation. The single-line configuration is ideal for filtering individual signal or power lines.



Housed in a standard 1206 (3216 Metric) package, the device measures 3.20mm x 1.60mm with a maximum height of 1.30mm. It is suitable for automated surface mount assembly and operates over a wide temperature range from -55°C to 125°C.

2512063017Y0 Quick Information

Product Type: Ferrite Bead
Canonical Name: Fair-Rite 2512063017Y0 Ferrite Bead, 300 Ohm @ 100 MHz, 350mA, 1206
Subcategory: Signal Line Ferrite Bead

2512063017Y0 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

2512063017Y0 Estimated Pricing

Qty Low High
1+ $0.35 $0.35
10+ $0.24 $0.24
25+ $0.21 $0.21
50+ $0.19 $0.19
100+ $0.18 $0.18
3,000+ $0.18 $0.18

Estimated market price range - modelled values for guidance only, not live distributor offers.

2512063017Y0 Features

  • 300 Ohm impedance at 100 MHz.
  • Rated for 350mA maximum current.
  • Low 200mOhm DC resistance.
  • Surface mount 1206 package.
  • Wide -55°C to 125°C range.

2512063017Y0 Applications

  • Suppresses noise on signal lines.
  • Used in DC power line filtering.
  • Suitable for high-frequency EMI suppression.
  • Ideal for compact SMD circuit designs.

2512063017Y0 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the impedance of the 2512063017Y0 ferrite bead?

The impedance is 300 Ohms at 100 MHz.

What is the maximum current rating for this ferrite bead?

The maximum DC current rating is 350mA.

What is the package size of the 2512063017Y0?

It comes in a 1206 (3216 Metric) surface mount package.

What is the operating temperature range?

The operating temperature range is -55°C to 125°C.

What is the DC resistance of this ferrite bead?

The maximum DC resistance is 200mOhm.
