This Wieland Electric 8142 Series PCB Terminal Block, part number 25.602.2253.0, offers a reliable solution for connecting multiple conductors to a PCB. It features 2 contacts with a 5mm pitch and a single row configuration.
The terminal block has a straight orientation and screw termination, with female contacts. The housing is made of thermoplastic material. It is rated for a current of 15A and a voltage of 300V. The dimensions are 10mm in length, 11.5mm in depth, and 13mm in width.
Designed for cable mounting, this PCB terminal block is suitable for mating with PCB headers. The conductors are connected via screw terminals, tightened using a conductor protective flat pin terminal. The recommended nominal cross-section for conductors is 2.5 mm².
This component originates from Germany and is part of the Wieland 8142 series.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.71 | $4.71 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This PCB terminal block has 2 contacts.
The pitch of this terminal block is 5mm.
The current rating for this terminal block is 15A.
The voltage rating of this PCB terminal block is 300V.
This terminal block uses cable mounting.
The nominal cross-section for conductors is 2.5 mm².
These plug-in terminals are rated at 10 A / 250 V.
