243-723 Wago 243-723 is a 1-position plug, female sockets, with PUSH WIRE® connection, 5.75mm pitch, rated 7A/150V UL and 6A/250V IEC, free hanging, orange.
Mfr Part #:

243-723

Available from 1 distributors
Mfr Name: Wago Corporation
Wago Corporation
Wago 243-723 is a 1-position plug, female sockets, with PUSH WIRE® connection, 5.75mm pitch, rated 7A/150V UL and 6A/250V IEC, free hanging, orange.
✓ Total Stock: 201 pcs
$ Price Range: $0.28

243-723 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Tomark Electronics Ltd ✓
Non-Authorised Inventory information
201 pcs
On Request
201 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

243-723 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Material
Contact Mating Finish
Contact Plating
Current
Depth
Height
Housing Material
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Plug Wire Entry
Positions Per Level
SVHC Present
Termination Style
Type
Voltage
Width
Wire Gauge or Range
View Similar Products (0)

243-723 Description

Short technical summary and product information.

The Wago 243-723 is a 1-position plug, female sockets, part of the MICRO PUSHWIRE® series. It features a screwless push-in spring connection (PUSH WIRE®) for solid conductors from 0.5 to 1 mm² (AWG 22-18). The pitch is 5.75mm, and it is designed for free hanging (in-line) mounting. The housing is orange polyamide (PA66) with V0 flammability rating. Electrical ratings: UL rated 7A at 150V, IEC rated 6A at 250V (overvoltage category III, pollution degree 3). Operating temperature range is -60°C to 105°C. The contacts are tin-plated electrolytic copper. Dimensions: width 5.75mm, height 10mm, depth 10.5mm. Strip length 5-6mm. This connector can be assembled into connector strips via dovetail joints. Suitable for solid conductor connections in various industrial applications.

243-723 Quick Information

Product Type: Terminal Block Plug, Female Sockets
Series: 243
Canonical Name: Wago 243-723 MICRO PUSHWIRE® PCB Connector, 1-Position Plug, Female Sockets, 5.75mm Pitch, Orange
Subcategory: Pluggable PCB Terminal Blocks

243-723 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

243-723 Estimated Pricing

Qty Low High
400+ $0.28 $0.28

Estimated market price range - modelled values for guidance only, not live distributor offers.

243-723 Features

  • PUSH WIRE® screwless termination for solid wires.
  • Rated 7A at 150V per UL 1059.
  • Rated 6A at 250V per IEC/EN 60664-1.
  • Free hanging mounting with 5.75mm pitch.
  • Orange polyamide housing, UL94 V-0 rated.

243-723 Applications

  • Ideal for solid conductor connections in control panels.
  • Used in building automation and lighting systems.
  • Suitable for industrial sensor and actuator wiring.
  • Can be assembled into multi-pole connector strips.

243-723 FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does the 243-723 have?

The 243-723 has 1 position.

What is the pitch of the 243-723?

The pitch is 5.75 mm.

What is the current rating of the 243-723?

UL rated current is 7 A; IEC rated current is 6 A.

What is the voltage rating of the 243-723?

UL rated voltage is 150 V; IEC rated voltage is 250 V.

What is the mounting type of the 243-723?

Free hanging (in-line) mounting.

What wire gauge does the 243-723 support?

Solid conductors from 0.5 to 1 mm² (AWG 22-18).
