| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Industrial Grade | |
| Input Connector | |
| Input Type | |
| Length | |
| Medical Grade | |
| Military Grade | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Voltage | |
| Width |
The Ideal Power Ltd. 23SW-00240271-S10B-US is an AC/DC desktop adapter with a power rating of 65W and an output voltage of 24V. It delivers a current of 2.71A and features an efficiency of 89%. This adapter is suitable for ITE (Commercial) applications and holds approvals from CE, cUL, FCC, GS, TUV, and UL.
The unit has a compact form factor, measuring 106.4mm in length, 71.1mm in width, and 34.2mm in height. It utilizes an IEC 320-C8 input connector and a barrel plug output connector (2.1mm I.D. x 5.5mm O.D. x 12.0mm) with positive center polarization. The operating temperature range is from 0°C to 40°C. It also features a low no-load power consumption of 100mW (Max).
This adapter is designed as a Desktop (Class II) unit and requires a cord, which is sold separately. The cord length is specified as 70.9" (1.80m). The product is compliant with RoHS3 standards and has an MSL rating of 1 Unlimited.
The output voltage is 24V DC at up to 2.71A, providing a total power of 65W.
The adapter operates from 0°C to 40°C.
The adapter achieves 89% efficiency at full load.
It is approved to CE, cUL, FCC, GS, TUV, and UL standards.
The input connector is an IEC 320-C8 (figure-8) type; the power cord is sold separately.
It is a Desktop (Class II) adapter with double insulation.
The no-load power consumption is 100mW maximum.
