| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,017 pcs
|
4017 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector System | |
| Contact Material | |
| Contact Plating | |
| Current | |
| Failure Rate | |
| Housing Material | |
| Number of Contacts | |
| Number of Rows | |
| Orientation | |
| Pitch | |
| Voltage |
This ERNI MiniBridge Series PCB header, part number 234450-E, is designed for wire-to-board applications. It features a 1.27mm pitch and a right-angle surface mount orientation, making it suitable for compact designs.
The header has 3 contacts with gold-plated copper alloy construction. It operates within a temperature range of -55°C to 125°C and has a voltage rating of 300V. The housing is made of Liquid Crystal Polymer, which withstands high temperatures for lead-free reflow soldering processes.
This component is ideal for diverse sensor, actuator, power-supply, and data applications in automotive and industrial electronics, computer technology, consumer electronics, and medical device technology. Despite its small dimensions, it offers a current capacity of up to 4A.
Key features include a shrouded design, a pick-and-place cover for automated assembly, and ruggedized metal clips for reliable retention force. Positioning pegs aid exact placement on the PCB.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 234450-E has an operating voltage of 300 V.
The 234450-E operates within a minimum temperature of -55 °C and a maximum temperature of 125 °C.
The pitch of the 234450-E connector is 1.27 mm.
The 234450-E has 3 contacts.
The 234450-E has a current rating of 4 A.
The 234450-E features a surface mount type.
The 234450-E has contacts made of Copper Alloy with Gold plating.
