This D-Sub connector assembly from TE Connectivity is a 25-position receptacle with female sockets arranged in two rows for standard DB-25 applications. It is designed for through-hole right-angle mounting and uses solder termination for secure board attachment. The contacts are gold flash finished, ensuring reliable signal transmission and corrosion resistance.
The connector features a steel shell with nickel plating for durability and EMI shielding. It includes a board lock feature to secure the connector to the PCB during soldering, and a housing/shell flange with 4-40 threaded inserts for mating with standard D-Sub plugs. The insulator is made of a material rated UL94 V-0 for flammability safety.
This connector is rated for 3A per contact and has a backset spacing of 8.08mm, making it suitable for applications requiring a right-angle interface to save board space. The shell layout is 3 (DB, B), indicating a standard DB-25 form factor.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.25 | $3.25 |
| 10+ | $2.56 | $2.56 |
| 50+ | $2.43 | $2.43 |
| 100+ | $2.17 | $2.17 |
| 250+ | $2.11 | $2.11 |
| 550+ | $2.06 | $2.06 |
| 1,100+ | $1.92 | $1.92 |
| 2,750+ | $1.86 | $1.86 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 25 positions arranged in 2 rows.
It is a Through Hole, Right Angle mount with Solder termination.
The current rating is 3 Amperes per contact.
The contacts have a Gold Flash finish.
The shell is made of Steel with a Nickel plating.
Yes, it includes a Board Lock feature.
