231-603/017-000 Wago 231-603/017-000 is a 3-pole through-panel PCB terminal strip with 5.00mm pitch, rated 15A and 300V, featuring screw rising cage clamp termination and mounting flanges.
Mfr Part #:

231-603/017-000

Available from 2 distributors
Mfr Name: Wago Corporation
Wago Corporation
Wago 231-603/017-000 is a 3-pole through-panel PCB terminal strip with 5.00mm pitch, rated 15A and 300V, featuring screw rising cage clamp termination and mounting flanges.
✓ Total Stock: 2,940 pcs

231-603/017-000 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
1,470 pcs
On Request
1470 pcs On Request 1 On Request On Request On Request On Request On Request
RAD ✓
Non-Authorised Inventory information
1,470 pcs
On Request
1470 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

231-603/017-000 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Current
Features
Lead Spacing
Lead Style
Mating Orientation
Mounting Type
Number of Levels
Pin Size
Pitch
Positions Per Level
Termination Style
Voltage
Wire Gauge
Wire Termination
View Similar Products (0)

231-603/017-000 Description

Short technical summary and product information.

The Wago 231-603/017-000 is a through-panel PCB terminal strip designed for reliable wire-to-board connections. It features 3 positions with a 5.00mm pitch and accepts wire gauges from 14 to 28 AWG. The terminal strip is rated for 15A current and 300V voltage, making it suitable for a variety of industrial and commercial applications.



Termination is via a screw rising cage clamp mechanism, ensuring secure and vibration-resistant wire connections. The component is mounted through-hole with angled solder pins measuring 1x1.2 mm. The body length is 18 mm, with an overall length of 23.8 mm. A mounting flange is included for additional mechanical stability.



The housing is gray and the mating orientation is horizontal with the board. This terminal strip is RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited).

231-603/017-000 Quick Information

Product Type: Through-panel PCB Terminal Strip
Canonical Name: Wago 231-603/017-000 Through-panel PCB Terminal Strip, 3-Pole, 5.00mm Pitch, Gray
Subcategory: Wire-to-Board Terminal Block

231-603/017-000 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 - Unlimited
REACH Status: REACH Unaffected

231-603/017-000 Features

  • 3-pole through-panel PCB terminal strip.
  • 5.00mm pitch with 15A/300V rating.
  • Screw rising cage clamp wire termination.
  • Accepts 14-28 AWG wire gauge.
  • Includes mounting flanges for stability.

231-603/017-000 Applications

  • Ideal for industrial control panel wiring.
  • Used in power distribution and signal connections.
  • Suitable for building automation systems.
  • Applicable in machinery and equipment interconnects.

231-603/017-000 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the Wago 231-603/017-000 have?

It has 3 positions (3-pole).

What is the pitch of this terminal strip?

The pitch is 5.00 mm (0.197 inches).

What is the current and voltage rating?

It is rated for 15 A and 300 V.

What type of wire termination does it use?

It uses a screw rising cage clamp termination.

What is the mounting type?

It is a through-hole mount component.
