231-368/001-000 This Wago 231-368/001-000 is an 8-pole THT male header with 5.08mm pitch and shrouded design. It features tin-plated contacts, vertical orientation, and through-hole solder termination.
Mfr Part #:

231-368/001-000

Available from 1 distributors
Mfr Name: Wago Corporation
Wago Corporation
This Wago 231-368/001-000 is an 8-pole THT male header with 5.08mm pitch and shrouded design. It features tin-plated contacts, vertical orientation, and through-hole solder termination.
✓ Total Stock: 1,040 pcs

231-368/001-000 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
1,040 pcs
On Request
1040 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

231-368/001-000 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Depth
Header Orientation
Height
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Positions Per Level
SVHC Present
Tape & Reel
Termination Style
Type
Voltage
Width
View Similar Products (0)

231-368/001-000 Description

Short technical summary and product information.

The Wago 231-368/001-000 is a THT male header from the MCS MIDI Classic series. It offers 8 positions in a single level with a 5.08mm pitch, and is designed for vertical through-hole soldering. The header is shrouded on four sides with tin-plated contacts.



Electrical ratings include 15A current and 600V voltage per UL 1059 (Use Group B/D), with a rated impulse withstand voltage of 4kV per IEC/EN 60664-1. The operating temperature ranges from -60°C to 100°C.



Mechanical dimensions are 43.76mm width, 17mm height, and 8.4mm depth. Solder pins are 1.2 x 1.2mm with a 5mm pin length. The housing is orange in color.

231-368/001-000 Quick Information

Product Type: Header, Male Pins, Shrouded
Series: 231
Canonical Name: Wago 231-368/001-000 THT Male Header, Shrouded, 8 Positions, 5.08mm Pitch, Through Hole, Solder
Subcategory: Shrouded Header

231-368/001-000 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 - Unlimited
REACH Status: REACH Unaffected

231-368/001-000 Features

  • 8 poles with 5.08mm pitch spacing.
  • Vertical through-hole solder termination.
  • Shrouded on four sides for protection.
  • Rated for 15A and 600V UL.
  • Tin-plated contact mating finish.

231-368/001-000 Applications

  • PCB-to-wire connections in control systems.
  • Industrial automation and building wiring.
  • Power distribution terminal blocks.

231-368/001-000 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does this header have?

This header has 8 positions arranged in a single level.

What is the pitch spacing?

The pitch is 5.08 mm (0.200 inches).

What is the current and voltage rating?

Rated current is 15 A (UL 1059 Use Group B/C) and 16 A (IEC/EN). Rated voltage is 600 V (UL 1059 Use Group B/D) and 250 V (IEC/EN, pollution degree 3).

What is the mounting type?

It is a through-hole (THT) mount component with solder termination.

What is the operating temperature range?

The operating temperature range is -60°C to 100°C.
