| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Depth | |
| Features | |
| Height | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Width | |
| Wire Gauge or Range |
The Wago 231-312/026-000 is a 1-conductor female plug connector from the MCS MIDI Classic series. It features 12 positions with a 5.08mm pitch and uses CAGE CLAMP® screwless push-in spring termination for fast and reliable wire connections. The connector accepts wire sizes from 0.08 to 2.5 mm² with a strip length of 8-9 mm.
Electrically, it is rated for 600V and 15A under UL 1977, with IEC ratings of 320V/16A depending on overvoltage category and pollution degree. The contact mating finish is tin, and the housing is orange. The plug includes retention latches on the non-wire side for secure mating.
Designed for free hanging (in-line) mounting, the connector has a width of 62.46 mm, height of 14.3 mm, and depth of 26.45 mm. It features variable coding and anti-rotation protection for reliable installation. The actuation tool can be used parallel or perpendicular to conductor entry.
This connector is suitable for use in industrial control systems, building automation, and other applications requiring a compact, high-density pluggable connection.
12 positions.
5.08 mm.
15 A under UL 1977, 16 A under IEC/EN 60664-1.
600 V under UL 1977, 320 V under IEC/EN 60664-1 (overvoltage category III/3).
Free hanging (in-line).
Screwless push-in spring (CAGE CLAMP®).
0.08 to 2.5 mm².
