| Category | |
| Manufacturer Name | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Tolerance | |
| Type | |
| Width |
The Murata Power Solutions 22R476MC is a wirewound fixed inductor designed for surface mount applications. It offers an inductance value of 47mH with a tolerance of ±10% and a DC resistance (DCR) of 154 Ohms.
This unshielded inductor has a current rating of 33mA and operates within a temperature range of -40°C to 85°C. Its mechanical dimensions are 7.80mm in length, 7.00mm in width, and 7.90mm in height.
The component's construction and specifications make it suitable for various electronic circuits requiring stable inductance. The surface mount package facilitates automated assembly processes.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $1.50 |
| 10+ | $0.60 | $1.20 |
| 100+ | $0.45 | $0.90 |
| 1,000+ | $0.30 | $0.60 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 47 mH.
The current rating is 33 mA.
The DC Resistance is 154 Ohm.
The tolerance is ±10%.
It is a wirewound type inductor.
No, it is unshielded.
The operating temperature range is -40°C to 85°C.
