| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6 pcs
|
6 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Large Diameter Recovered | |
| Large Diameter Supplied | |
| Large Recovered Length | |
| Material | |
| Shell Size | |
| Small Diameter Recovered | |
| Small Diameter Supplied | |
| Small Recovered Length | |
| Total Length Recovered | |
| Type |
The TE Connectivity 222K152-3-0 is a right angle (90°) heat shrink boot designed for size 52 shell applications. It is constructed from semi-rigid polyolefin and colored black for identification. The boot provides a supplied large diameter of 36.07mm and recovers to 22.4mm, while the supplied small diameter of 36.07mm recovers to 8.41mm. The total recovered length is 45.97mm, with a large recovered length of 38.0mm and a small recovered length of 24.99mm. Its environmental compliance includes RoHS3 (listed), REACH unaffected, and MSL 1 unlimited. This boot is used for cable harness strain relief and environmental sealing of connectors.
| Qty | Low | High |
|---|---|---|
| 1+ | $30.70 | $30.70 |
| 10+ | $26.53 | $26.53 |
| 25+ | $25.15 | $25.15 |
| 50+ | $24.16 | $24.16 |
| 100+ | $23.01 | $23.01 |
| 250+ | $21.57 | $21.57 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The product is listed as RoHS3 Compliant (unverified).
It is made from semi-rigid polyolefin (PO).
Black.
Shell size 52.
Large recovered diameter 22.4mm, small recovered diameter 8.41mm.
