| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Ambient Temperature | |
| Approval Agency | |
| Breaker Type | |
| Country of Origin | |
| Current Rating | |
| Current Rating (Amps) | |
| Height | |
| Illumination | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Terminal Type | |
| Voltage Rating | |
| Width |
This E-T-A 2210 Series thermal magnetic circuit breaker, part number 2210-T210-K0M1-H121-1.5A, provides reliable overload and short circuit protection. It is a single-pole unit with a current rating of 1.5A and a maximum AC voltage rating of 480V.
The breaker features a thermal-magnetic tripping mechanism and a toggle actuator for manual operation. It is designed for DIN rail mounting, making it suitable for integration into control panels and industrial equipment. The compact width of 12.5mm allows for high-density packaging.
Typical applications for this circuit breaker include process control equipment, robotics, machine tool control, communications systems, and instrumentation. It is approved to CBE standard EN 60934 (IEC 60934) and meets various international standards including UL, CSA, and VDE.
Additional specifications include a DC voltage rating of 65V, a breaking capacity of 25A, and an operating ambient temperature range of -30°C to +60°C. The unit also includes an auxiliary contact for remote status signaling.
The current rating is 1.5A.
The rated AC voltage is 480V.
This circuit breaker has 1 pole.
It uses a thermal magnetic tripping mechanism.
The mounting type is DIN Rail.
The ambient temperature range is -30°C to +60°C.
Yes, it has an auxiliary circuit rated for 1 A, AC 240 V / DC 65 V, resistive.
