This E-T-A 2210-S211-P1M1-Z141-1.5A is a single-pole thermal-magnetic circuit breaker approved to EN 60934 (IEC 60934) and UL1077 standards. It features a trip-free mechanism and toggle actuation, suitable for panel mounting.
With a current rating of 1.5A and a voltage rating of 250VAC (or 65VDC), this circuit breaker is designed for reliable overcurrent protection. It has an interrupting capacity of 400A at 0.1-5A and 800A at 6-25A. The operating temperature range is -30°C to +60°C.
Typical applications include process control equipment, robotics, machine tool control, communications systems, and instrumentation. The breaker is built for durability with a typical life of 10,000 operations at 1x IN inductive load. It also includes auxiliary contacts for status signaling.
Key technical data includes a 2.5 kV insulation withstand voltage, IP30 degree of protection for the operating area, and compliance with vibration and shock standards. The unit weighs approximately 50g per pole.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The voltage rating is 250 VAC, 3 AC 433 V (50-60Hz), and 65 VDC. The UL rating is AC 277/480 V and DC 65 V.
The current rating is 1.5A.
This circuit breaker has 1 pole.
It supports panel mounting.
The operating temperature range is -30°C to +60°C.
It is approved to CSA C22.2 No 235, GB 17701, IEC 60934, and UL1077.
The interrupting capacity (Icn) is 400A for 0.1-5A and 800A for 6-25A. The UL 1077 interrupting capacity is 2,500A at DC 32V.
