| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
76 pcs
|
76 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Conductor Material | |
| Depth | |
| Height | |
| Mounting Type | |
| Number of Conductors | |
| Operating Temperature | |
| Rated Current | |
| SVHC Present | |
| Width |
The Wago 221-415 is a 5-conductor splicing connector designed for flexible and safe connections. It utilizes lever actuation, allowing users to simply pull the lever up, insert a conductor, and push the lever back down to complete the connection. This tool-free operation saves time for installers and device manufacturers.
This connector is suitable for all conductor types, including solid, stranded, and fine-stranded copper conductors, with cross-sections ranging from 0.14 mm² to 4 mm². It boasts electrical ratings of 450V and 32A, with a rated surge voltage of 4kV. The surrounding air temperature must not exceed 85°C (T85).
Key mechanical dimensions include a width of 30mm, a height of 8.4mm, and a depth of 18.8mm. The connector features a transparent housing and is designed for side-entry wiring. It is compatible with mounting carriers for installation according to standards.
The Wago 221-415 is intended for use by electricians only and requires adherence to installation and safety instructions, including national regulations and technical specifications for connected products.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Wago 221-415 can connect solid, stranded, and fine-stranded copper conductors.
The 221-415 supports a maximum conductor size of 4 mm².
The connector is rated for a nominal voltage of 450V, a rated surge voltage of 4kV, and a rated current of 32A.
The maximum surrounding air temperature for the 221-415 is 85°C (T85).
The 221-415 features lever actuation for easy conductor insertion and is compatible with mounting carriers for installation.
