| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector System | |
| Contact Material | |
| Contact Plating | |
| Current Rating | |
| Failure Rate | |
| Housing Material | |
| Number of Contacts | |
| Number of Rows | |
| Orientation | |
| Pitch | |
| SVHC Present | |
| Termination Style | |
| Voltage Rating |
This Molex 22-27-2141 is a straight-through hole pin header from the KK 254 series. It features 14 male contacts made of brass with tin plating, designed for wire-to-board applications. The connector has a pitch of 2.54mm and a row pitch of 2.54mm, with a single row configuration. It is unshrouded and mounts via a through-hole termination style, suitable for soldering.
The header is constructed with a nylon housing and operates within a temperature range of -40°C to 105°C. It has a voltage rating of 250V and a current rating of 4A. The mating pin length is 2.54mm. This component is designed for reliable connections in various electronic applications.
Key specifications include 14 contacts, a 2.54mm pitch, and a straight orientation. The through-hole mounting and solder termination make it suitable for PCB assembly. The KK 254 series is known for its versatility in interconnecting wires and boards.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
14 positions.
2.54 mm.
4A.
250V.
Through hole.
-40°C to +105°C.
Brass with tin plating.
