21420100002401 Harting 21420100002401 M8 insert shell for female sockets, female gender, panel mount with bulkhead front side nut, IP67 rated.
Mfr Part #:

21420100002401

Available from 1 distributors
Mfr Name: Harting
Harting
Harting 21420100002401 M8 insert shell for female sockets, female gender, panel mount with bulkhead front side nut, IP67 rated.
✓ Total Stock: 50 pcs

21420100002401 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
50 pcs
On Request
50 pcs On Request 1 On Request On Request 2026-02-25 06:16:38 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

21420100002401 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Country of Origin
Gender
Mounting Feature
Mounting Type
Prop 65
SVHC Present
Shell Size
Shielding
Type
View Similar Products (0)

21420100002401 Description

Short technical summary and product information.

The Harting 21420100002401 is an M8 insert shell accessory for circular connectors, designed for female sockets. This panel mount housing features a bulkhead front side nut mounting style and is unshielded. It provides IP67 ingress protection when mated, per IEC 60529. The housing has a mounting height of 11 mm and a tightening torque of 1 Nm for the lock nut. Constructed from a copper alloy, it is RoHS compliant with exemption 6(c) for lead content up to 4% by weight. This component is part of the Harting M8 series and is manufactured in Germany.

21420100002401 Quick Information

Product Type: Circular Connector Housing
Series: M8
Canonical Name: Harting M8 Insert Shell for Female Sockets, Panel Mount, IP67
Subcategory: Circular Connector Housing

21420100002401 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Compliant

21420100002401 Features

  • M8 insert shell for female sockets.
  • Panel mount with front side nut.
  • IP67 rated when mated.
  • Tightening torque 1 Nm for lock nut.
  • Unshielded design for general use.

21420100002401 Applications

  • Used in industrial automation systems.
  • Suitable for sensor and actuator connections.
  • Ideal for harsh environment panel interfaces.

21420100002401 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the IP rating of this housing?

IP67 in mated condition according to IEC 60529.

What is the tightening torque for the lock nut?

1 Nm.

Is this housing shielded?

No, it is unshielded.

What is the mounting type and feature?

Panel mount with bulkhead front side nut.

What is the shell size?

M8.

What is the country of origin?

Germany.

What is the net weight?

6.16 g.
