| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| California Proposition 65 | |
| China RoHS | |
| Coding | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Mating Side | |
| Contact Resistance | |
| Country of Origin | |
| Current Rating (Amps) | |
| ELV | |
| Features | |
| Fire Protection | |
| Flammability Class | |
| GTIN | |
| Gender | |
| Insulation Resistance | |
| Isolation Group | |
| Lead Style | |
| Material (Contacts) | |
| Material (Insert) | |
| Mating Cycles | |
| Mounting Type | |
| Net Weight | |
| Number of Contacts | |
| Number of Positions | |
| Operating Temperature | |
| Operating Temperature Range | |
| Orientation | |
| Overvoltage Category | |
| Packaging Size | |
| Packaging Type | |
| Pollution Degree | |
| Rated Current | |
| Rated Impulse Voltage | |
| Rated Voltage | |
| SVHC Present | |
| Shell Size | |
| Shielding | |
| Standard Package Qty | |
| Standards | |
| Surface (Contacts) | |
| Termination | |
| Termination Method | |
| Voltage Rating |
The HARTING 21033212518 is a female M12 PCB receptacle insert designed for use in circular connector assemblies. It features 5 contacts with A-coding, ensuring correct keyed mating in M12 connector systems. The insert is shielded for electromagnetic compatibility and uses gold-plated contacts over nickel for reliable signal integrity and corrosion resistance.
Electrical ratings include a current rating of 4 A and a voltage rating of 60 V, with an impulse voltage of 1.5 kV. The insulation resistance exceeds 10^8 Ω and contact resistance is ≤10 mΩ, making it suitable for demanding industrial environments. The component operates over a temperature range of -40°C to 85°C and is classified with pollution degree 3 and overvoltage category III.
The insert is mounted via through-hole with reflow soldering termination (THR) and comes packaged in a tray of 60 pieces. It is intended for use with a separately ordered M12 housing shell. The insert body is made of liquid crystal polymer (LCP) with UL 94 V-0 flammability rating, and the contacts are copper alloy.
This insert has 5 positions (contacts).
The rated current is 4 A.
The rated voltage is 60 V with a rated impulse voltage of 1.5 kV.
It uses through-hole mounting with reflow soldering termination (THR).
The operating temperature range is -40°C to 85°C.
Yes, it is shielded for electromagnetic compatibility.
The insert is made of liquid crystal polymer (LCP) with UL 94 V-0 flammability rating.
