20VR6 Single phase power line filter rated for 20A at 250VAC. Two-stage design with chassis mount and threaded post terminals.
Mfr Part #:

20VR6

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
Single phase power line filter rated for 20A at 250VAC. Two-stage design with chassis mount and threaded post terminals.
✓ Total Stock: 8,200 pcs
$ Price Range: $59.52 - $69.43

20VR6 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
8,200 pcs
On Request
8200 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

20VR6 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Configuration
Current
Filter Type
Frequency
Inductance
Mounting Type
Operating Temperature
Termination Style
Voltage
View Similar Products (0)

20VR6 Description

Short technical summary and product information.

TE Connectivity's 20VR6 is a single phase power line filter designed for general purpose applications. It features a two-stage filtering configuration rated for 20A continuous current at 250VAC, 50/60Hz. The filter provides 880µH of inductance to attenuate conducted EMI on the power line.



The filter is chassis mounted with threaded post (8-32) terminations for secure electrical connections. It operates over a temperature range of -10°C to 40°C. The component carries CSA, UR, and VDE safety approvals, indicating compliance with North American and European standards.



This filter is suitable for use in equipment requiring EMI suppression on single phase AC power inputs. Its two-stage design offers higher attenuation compared to single-stage filters, making it appropriate for applications with moderate to high noise levels.

20VR6 Quick Information

Product Type: Power Line Filter Module
Canonical Name: TE Connectivity 20VR6 Single Phase Power Line Filter, 20A, 250VAC, Chassis Mount
Subcategory: Single Phase Filter

20VR6 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

20VR6 Estimated Pricing

Qty Low High
1+ $69.43 $69.43
12+ $62.38 $62.38
112+ $59.52 $59.52

Estimated market price range - modelled values for guidance only, not live distributor offers.

20VR6 Features

  • Single phase two-stage EMI filter design.
  • Rated for 20A at 250VAC operation.
  • Chassis mount with threaded post terminals.
  • 880µH inductance for effective filtering.
  • CSA, UR, VDE safety approved.

20VR6 Applications

  • Used in general purpose power line filtering.
  • Suitable for industrial equipment EMI suppression.
  • Ideal for single phase AC input applications.

20VR6 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage of the 20VR6 filter?

250VAC.

What is the operating temperature range?

-10°C to 40°C.

Is the 20VR6 RoHS compliant?

Yes, RoHS3 compliant (unverified).

What is the current rating?

20A.

What is the mounting type?

Chassis mount with threaded post (8-32) terminals.

What safety approvals does the 20VR6 have?

CSA, UR, VDE.

What is the inductance value?

880µH.
