| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
36 pcs
|
36 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Configuration | |
| Current | |
| Filter Type | |
| Frequency | |
| Inductance | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| Termination Style | |
| Voltage |
The TE Connectivity 20VB1 is a single-phase power line filter module designed for general-purpose applications. It provides EMI filtering with a rated inductance of 440 µH and operates at 50/60 Hz.
This filter is rated for a maximum voltage of 250VAC and a continuous current of 20A. It is a single-stage configuration, offering effective noise suppression for AC power lines. The operating temperature range is -10°C to 40°C.
The filter features a chassis mount design with quick connect terminals for easy installation. It is approved by CSA, UR, and VDE, ensuring compliance with international safety standards. The component is RoHS3 compliant and has an MSL of 1 (unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $34.95 | $34.95 |
| 12+ | $29.47 | $29.47 |
| 24+ | $28.92 | $28.92 |
| 48+ | $28.22 | $28.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
250VAC.
-10°C to 40°C.
Yes, RoHS3 compliant (unverified from source).
20A.
Chassis mount.
Quick connect.
