| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Country of Origin | |
| Depth | |
| Diameter | |
| Dissipation Factor | |
| Failure Rate | |
| Height | |
| Length | |
| Technology | |
| Tolerance | |
| Voltage |
This Panasonic 20SVP68M is a polymer capacitor designed for surface mount applications. It offers a capacitance of 68µF and a voltage rating of 20V dc, with a tolerance of ±20%.
The capacitor features a solid electrolyte and a polymer technology, contributing to its reliability and performance. It has a maximum operating temperature of 105°C and a minimum operating temperature of -55°C. The ripple current is rated at 2400mA, and the leakage current is 272μA.
With a diameter of 10mm, height of 7.9mm, and length of 7.9mm, this component is suitable for various industrial and ICT applications. The SVP series capacitors are known for their excellent noise reduction capabilities and long life span, guaranteed for 2000 hours at +105°C.
Recommended for use in industrial PCs, motor drivers, power supplies, and automotive applications, this capacitor provides high voltage and high reliability. Its low ESR and high ripple current handling make it suitable for demanding environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
68µF.
20V dc.
±20%.
-55°C to +105°C.
Surface mount package.
2400mA.
Yes, it is a polarized capacitor.
