The Bel Power Solutions 20IMX7-24-24-8G is a 7W isolated DC-DC converter from the IMX7 series. It is a conformal coated module designed for reliable operation in commercial and railway applications. The converter provides two fully isolated 24V outputs, each capable of delivering 130mA, making it suitable for distributed power architectures.
Electrical specifications include a typical efficiency of 83%, with an isolation voltage rating of 1500VAC to 2000VAC. The module operates over a wide ambient temperature range of -40°C to 85°C. Protection features include overcurrent (OCP), overtemperature (OTP), overvoltage (OVP), short-circuit (SCP), and undervoltage lockout (UVLO). A remote on/off function is also provided.
The converter is housed in a 14-DIP through-hole package measuring 50.8mm x 25.4mm x 10.4mm (2.00" x 1.00" x 0.41"). Planar technology ensures excellent mechanical stability. The series is designed to meet immunity standards IEC/EN 61000-4-2, -3, -4, -5, -6. The part is listed as RoHS3 compliant and REACH unaffected, though these compliance claims are unverified. Applications include ITE (commercial) and railway systems.
The converter provides dual isolated outputs, each 24V at 130mA.
The total power output is 7W.
Typical efficiency is 83%.
The isolation voltage is 1500VAC to 2000VAC.
The converter operates from -40°C to 85°C.
It is a 14-DIP through-hole module.
The part is listed as RoHS3 compliant, but the compliance status is unverified.
