| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Current | |
| Current Rating | |
| Disconnect Type | |
| Height | |
| Insulation Material | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Terminal | |
| Terminal Block Type | |
| Termination Style | |
| Type | |
| Voltage | |
| Voltage Rating | |
| Weight | |
| Width | |
| Wire Gauge or Range |
The Wago 2002-1761 is a 3-conductor carrier terminal block designed for disconnect applications. It features push-in CAGE CLAMP® connection technology, allowing fast and reliable wire termination without tools for solid conductors from 0.75 to 4 mm². The terminal block accepts solid and fine-stranded copper conductors from 0.25 to 4 mm² (22 to 12 AWG).
Rated at 300V and 15A per UL 1059, and 400V and 16A per IEC/EN 60947-7-1, this block provides a rated surge voltage of 6 kV. The disconnect function is implemented via a disconnect tab, enabling easy isolation of circuits. The housing is made of gray polyamide (PA66) with a flammability rating of V0 per UL94.
Mounting is on DIN-35 rail (35 x 15 mm or 35 x 7.5 mm). The block has a width of 5.2 mm, height of 76.8 mm, and depth from rail of 32.9 mm. It includes 3 connection points, 2 potentials, and 2 jumper slots for bridging. The operating temperature range is -35 to +85 °C, with a continuous operating temperature starting at -60 °C (upper limit not specified in available data).
It has 3 positions (connection points).
Rated 300 V per UL 1059 and 400 V per IEC/EN 60947-7-1.
Rated 15 A per UL 1059 and 16 A per IEC/EN 60947-7-1.
It mounts on DIN-35 rail (35 x 15 mm or 35 x 7.5 mm).
Solid and fine-stranded copper conductors from 0.25 to 4 mm² (22 to 12 AWG).
It uses a disconnect tab for circuit isolation.
V0 per UL94.
