| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
15 pcs
|
15 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Board | |
| Board Pitch | |
| Cable Pitch | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Row Spacing | |
| Wire Gauge |
The TE Connectivity 2-746610-4 is a 60-position DIP header IDC connector designed for board-in, direct wire-to-board applications. It features a 2-row configuration with a row spacing of 2.54mm (0.100") and a board pitch of 2.54mm (0.100"). The cable pitch is 1.27mm (0.050"), and the connector uses IDC (Insulation Displacement Contact) termination for ribbon cable.
The connector is through hole mounted and accepts 26-28 AWG stranded or 26-30 AWG solid wire. Contacts are finished with tin (2.54µm thickness) for reliable conductivity. The housing is black and includes a feed-through feature for pass-through wiring.
This connector is suitable for applications requiring a high-density, reliable interconnection between a PCB and a ribbon cable. The 60-position count and dual-row design make it ideal for parallel data transmission or signal distribution in industrial, telecommunications, or computing equipment.
The connector has 60 positions.
The row spacing is 2.54mm (0.100").
The mounting type is through hole.
It accepts 26-28 AWG stranded or 26-30 AWG solid wire.
The contact finish is tin with a thickness of 2.54µm (100.0µin).
Yes, it includes a feed-through feature.
